Polyworks Probing Package

PolyWorks Inspector with Probing Package is a powerful industrial 3D metrology software solution to control tool or part dimensions, diagnose and prevent manufacturing and assembly issues, guide assembly building through real-time measurements, and oversee the quality of assembled products by using non-contact point cloud digitizers and single-point contact-based probing devices.

Probing Package Features:

• Single-point measuring device support: All available plug-ins for articulated arms, optically tracked probes, laser trackers, manual CMMs, and theodolites
• IGES/STEP neutral CAD file translator: Import of IGES and STEP files
• Part alignment toolset: Powerful set of data-to-CAD alignment techniques that include constrained surface and cross-sectional best-fit, best-fit within tolerance, as well as techniques based on features, reference points, flush and gap gauges, and more
• Dimensional control toolset: Widest range of dimensional control tools on the market for a complete analysis of surface, boundary, and cross-sectional deviations, feature dimensions, flush and gap, profile radius, clearance, thickness, and more
• Smart GD&T toolset: GD&T engine based on algorithms prescribed by the ASME Y14.5-2009 and ISO 1101 standards, advanced Datum Reference Frame capabilities (supports datum feature patterns, composite datum features, and datum targets), tolerance zone size and mobility modifiers, radial and slab-like tolerance zones, and more
• Native CAD file translators: Optional translators to import CAD models produced by professional CAD solutions: CATIA V6/V5, CATIA V4, NX (UG), Creo (Pro/E), Inventor, Parasolid, and SolidWorks
• Airfoil gauges: Optional comprehensive dimensional analysis solution for fan, compressor, and turbine blades
